Fat Jeetrike Handcycle
The Fat Jeetrike offers enhanced traction and comfort with super wide, balloon tires for superior performance on snow, sand, and mud.
The Fat Jeetrike Off-Road Handcycle features full independent suspension and rear wheel drive for extreme traction, further enhanced by its FAT tires. Its comfortable seating allows for hours on challenging trails, offering full control on bumps. Available in manual drive, electric assist, or all-electric drive options, it suits various needs.
With the new 4-link suspension, the Fat Jeetrike achieves a short wheelbase for improved frame stiffness and drive wheel grip, while also reducing the turning radius for better manoeuvrability. Suitable for most people with a range of disabilities, including quadriplegia, it is the ultimate choice for off-road adventures.
Explorer is also available with an electric assist.
For more information, contact Adaptive Concepts on 0407 502 729 or complete the enquiry form below.
Handcycle Options:
- Electric assist increased to 750W
- Rear lights
- Safety belt
- Schlumpf Mountain-Drive
- FAT 26″ SPORT-ON carbon wheels
- Water bottle basket
- Main battery
- Version for persons with tetraplegia
- Front lights
- Safety flag
- Spare battery
| Component | Specification |
|---|---|
| Frame | 6082 aluminium alloy |
| Wheels | 26×4.0” |
| Front suspension | CNC double wishbone |
| Rear suspension | multi-link |
| Shock absorbers | RockShox Monarch R |
| Steering system | simultaneous driving and steering owing to a combination of functions |
| Drive system | 500W central motor (assist mode only) |
| Battery | 12Ah, range 25-100km depending on terrain |
| Rear hub | Rohloff Speedhub 500/14 XL FAT |
| Seat | carbon, adjustable |
| Footrest | aluminium, adjustable |
| Brakes | Shimano ZEE hydraulic |
| Brake discs | 203mm front / 180mm rear |
| Dimensions with wheels | L=203cm W=101cm H=99cm |
| Weight | come on – it’s electric assist! |
